Aprilog makes & stocks IC adapters for QFP, TQFP, QFN, MLF, SOIC, SSOP, TSSOP, TSOP, VSOP, SOP, PLCC, PGA & SOT packages and stocks test sockets by Enplas, Plastronics, Sensata, Yamaichi & Tokyo Electech. Programming adapters, IC footprint chip changing adapters, and ZIF socket to PCB pads adapters. Adapters for Microchip PIC, Intel, NXP, ST, Freescale, and many more. We also build custom adapters to meet your special needs.

ZIF Test Socket to Breadboard adapters



These adapters consist of a highest quality ZIF test socket connected to a circuit card with pins spaced on 0.1 inch centers for mounting on standard prototype breadboards. All pins and pads are wired one to one.

    Solder tail and square wire wrap pins.

Adapters on these pages are listed in ascending order by the number of pins

3 Pins 4 Pins 5 Pins 6 Pins 8 Pins 10 Pins
14 Pins 16 Pins 20 Pins 24 Pins 28 Pins 32 Pins
36 Pins 38 Pins 40 Pins 44 Pins 48 Pins 54 Pins
56 Pins 64 Pins 66 Pins 68 Pins 80 Pins 100 Pins
128 Pins 144 Pins 160 Pins 208 Pins 256 Pins


Part Number   3 Pin    Price Shopping Cart
TO263-D6-ZL-S D2 PAK, JEDEC TO-263 package to DIP adapter with closed top ZIF socket 3 Pin D2 PAK, JEDEC TO-263 package to DIP adapter with closed top ZIF socket.
  • 3 Pins
  • 10.29mm (405 mil) Max package width
  • 9.65mm (380 mil) Max molded package length - Plus the 1.68mm (0.066") metal tab
  • 2.54 mm (100 mil) Pitch
  • Compatible D2 PAK, JEDEC TO-263 Package
  • Status - In stock End of life. 20 Each left in stock
  • Closed top Sensata 499-040-20 ZIF socket
  • Bottom pins are 18 mil diameter round solder-tail
  • DIP rows 600 mils apart
$63.00
SOT23-3-D3-ZL-S 3 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. 3 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. $44.00

Part Number   4 Pin    Price Shopping Cart
SOT-89-4-D3-ZL 4 Pin TO-243(JEDEC) SOT-89 to DIP adapter 4 Pin TO-243(JEDEC) SOT-89 to DIP adapter with closed top ZIF socket.
  • For 4 Pin TO-243(JEDEC) SOT-89 package
  • 4 Pins
  • 2.64mm (104 mil) Max package width
  • 4.57mm (180 mil) Max package length
  • 1.73mm (68 mil) Tab Single contact centered on one side.
  • 3.0mm (118 mil) Pitch on the other side.
  • Compatible SOT89 JEDEC TO-243 Package
  • Mfr. Sensata Technologies (Formerly Wells-CTI)
  • Closed top Sensata 499-P37-20 ZIF socket
  • Bottom pins are 25 mil square wire wrap
  • DIP rows 300 mils apart
$44.00
SOT-223-D3-ZL   SOT223-1, JEDEC TO-261, Package to DIP adapter with closed top ZIF socket. 4 Pin SOT223-1, JEDEC TO-261, Package to DIP adapter with closed top ZIF socket. $44.00
SOT-223-D3-ZL-P   SOT223-1, JEDEC TO-261, Package to DIP adapter with closed top ZIF socket. 4 Pin SOT223-1, JEDEC TO-261, Package to DIP adapter with closed top ZIF socket. $44.00

Part Number   5 Pin    Price Shopping Cart
SC70-5-D3-ZL 5 Pin MO-178 adapter with closed top ZIF socket 5 Pin SC-70, SOC-353 Package to DIP adapter with closed top ZIF socket. $59.00
SC70-5-D6-ZL 5 Pin MO-178 adapter with closed top ZIF socket 5 Pin SC-70, SOC-353 Package to DIP adapter with closed top ZIF socket. $59.00
SC70-5-K-ZL-D3 5 Pin </b>Closed top Kelvin connection socket for SC70 MO-203 Small Outline Transistor package to 300 mil DIP rows. 5 Pin Closed top Kelvin connection socket for SC70 MO-203 Small Outline Transistor package to 300 mil DIP rows. $96.00
SC70-5-K-ZL-D6 5 Pin </b>Closed top Kelvin connection socket for SC70 MO-203 Small Outline Transistor package to 600 mil DIP rows. 5 Pin Closed top Kelvin connection socket for SC70 MO-203 Small Outline Transistor package to 600 mil DIP rows.
  • Closed top test socket
  • 5 Pins
  • 1.1-1.4mm (43-55) Max package width
  • 1.85-2.15mm (73-85) Max package length
  • Compatible SC70 MO-203 Package Drawing
  • DIP pins are 25 mil square and are in rows 600 mils apart
$96.00
SOT23-5-D3-ZL-P 5 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. 5 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. $44.00
SOT23-5-D3-ZL-S 5 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. 5 Pin MO-178 SOT-23 to DIP adapter with closed top ZIF socket. $44.00

Part Number   6 Pin    Price Shopping Cart
PIC10F200-SO23-6P 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin PIC10F200, PIC10F204, PIC10F202 PIC10F206 SO23 6 pin to 8 DIP adapter. DIP pins have the same signals as the DIP version of the chip. SO-23 ZIF socket. Adapts from SO-23 package to PIC10F20x DIP socket. $44.00
PIC10F200-SO23-6S 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin PIC10F200, PIC10F204, PIC10F202 PIC10F206 SO23 6 pin to 8 DIP adapter. DIP pins have the same signals as the DIP version of the chip. SO-23 ZIF socket. Adapts from SO-23 package to PIC10F20x DIP socket. $44.00
SC70-6-D3-ZL 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin SC-70, SOC-353 Package to DIP adapter with closed top ZIF socket.
  • For 6 Pin SC-70, SOC-353 Package Type
  • 6 Pins
  • 1.25mm (49.2 mils) Max package width
  • 2.00mm (78.7 mils) Max package length
  • 0.9mm (35.4 mils) Package height
  • 0.065mm (25.6 mils) Pitch
  • Compatible SC-70-6, SOC-353 Package
  • Closed top Yamaichi SMT-26420-1 ZIF socket
  • Bottom pins are DIP rows 300 mils apart
  • Bottom pins are 25 mil square wire wrap.
$59.00
SC70-6-D6-ZL 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin SC-70, SOC-353 Package to DIP adapter with closed top ZIF socket.
  • For 6 Pin SC-70, SOC-353 Package Type
  • 6 Pins
  • 1.25mm (49.2 mils) Max package width
  • 2.00mm (78.7 mils) Max package length
  • 0.9mm (35.4 mils) Package height
  • 0.065mm (25.6 mils) Pitch
  • Compatible SC-70, SOC-353 Package
  • Closed top Yamaichi SMT-26420-1 ZIF socket
  • Bottom pinsare DIP rows 600 mils apart
  • Bottom pins are 25 mil square wire wrap.
$59.00
SOT23-6-8D3-ZL-S-24AA04-S 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin SO-23 ZIF socke do DIP. $44.00
SOT23-6-8D3-ZL-S-24AA04-P 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin SO-23 ZIF socke do DIP. $44.00
SOT23-6-8D3-ZL-S-93AA66-S 6 Pin MO-178 adapter with closed top ZIF socket 6 Pin SO-23 ZIF socke do DIP. $44.00
SOT23-6-8D3-ZL-S-93AA66-P 6 Pin MO-178 adapter with closed top ZIF socket 6 PinSO-23 ZIF socke do DIP. $44.00
SOT23-6-D3-ZL-P SOT23 adapter with closed top ZIF socket 6 Pin SOT23-6, MO178 to DIP adapter with closed top ZIF socket. $44.00
SOT23-6-D3-ZL-S SOT23 adapter with closed top ZIF socket 6 Pin SOT23-6, MO178 to DIP adapter with closed top ZIF socket. $44.00

Part Number   8 Pin    Price Shopping Cart
8DFN20-D6-ZL-P 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • 8 Pins, 4 each on the two sides
  • QFN to DIP pins are wired 1 to 1
  • 2.0 x 2.0mm (0.0787 inches inches) Square package body
  • Additional IC center pad contact
  • 0.5mm (20 mil) pitch
  • Plastronics 008QN50L22020S Clamshell socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 600 mils apart
$122.00
8DFN20-D6-ZL-S 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • 8 Pins, 4 each on the two sides
  • QFN to DIP pins are wired 1 to 1
  • 2.0 x 2.0mm (0.0787 inches inches) Square package body
  • Additional IC center pad contact
  • 0.5mm (20 mil) pitch
  • Plastronics 008QN50L22020S Clamshell socket
  • Bottom are 18 mil, round solder tail
  • Bottom pins are DIP rows 600 mils apart
$122.00
8QN50-D3-ZL-S 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 pin QFN package
  • QFN to DIP pins are wired 1 to 1
  • 6.0 X 5.0mm Chip body
  • 1.27mm (50 mil) Pitch
  • Plastronics 08QN12T16050 Clamshell socket
  • Bottom pins are round 18 mil solder tail pins
  • DIP rows 300 mils apart
$122.00
8QN50-D3-ZL-P 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 pin QFN package
  • QFN to DIP pins are wired 1 to 1
  • 6.0 X 5.0mm Chip body
  • 1.27mm (50 mil) Pitch
  • Plastronics 08QN12T16050 Clamshell socket
  • Bottom are square 25 mil wire wrap pins
  • DIP rows 300 mils apart
$122.00
8QN50-D6-ZL 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 pin QFN package
  • QFN to DIP pins are wired 1 to 1
  • 6.0 X 5.0mm Chip body
  • 1.27mm (50 mil) Pitch
  • Plastronics 08QN12T16050 Clamshell socket
  • Bottom pins are round 18 mil solder tail pins
  • Bottom pins are DIP rows 600 mils apart
$122.00
8QN50-D6-ZL-P 8 Pin QFN adapter with closed top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 pin QFN package
  • QFN to DIP pins are wired 1 to 1
  • 6.0 X 5.0mm Chip body
  • 1.27mm (50 mil) Pitch
  • Plastronics 08QN12T16050 Clamshell socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 600 mils apart
$122.00
8QN51-D3-ZO 8 Pin QFN adapter with open top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 Pins, 4 each on the two shortest sides
  • QFN to DIP pins are wired 1 to 1
  • 8.0mm (0.315 inches) Package body width
  • 6.0mm (0.236 inches) Package body length
  • 4 Additional IC center pad contacts
  • 1.3mm (51 mil) pitch
  • DIP pins are round solder tail
  • Compatible SOIC Package Drawing
  • Plastronics 08QN12T18060 Open top socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 300 mils apart
$122.00
8QN51-D3-ZO-P 8 Pin QFN adapter with open top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 Pins, 4 each on the two shortest sides
  • QFN to DIP pins are wired 1 to 1
  • 8.0mm (0.315 inches) Package body width
  • 6.0mm (0.236 inches) Package body length
  • 4 Additional IC center pad contacts
  • 1.3mm (51 mil) pitch
  • DIP pins are 25 mil square wire-wrap
  • Compatible SOIC Package Drawing
  • Plastronics 08QN12T18060 Open top socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 300 mils apart
$122.00
8QN51-D6-ZO 8 Pin QFN adapter with open top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 Pins, 4 each on the two shortest sides
  • QFN to DIP pins are wired 1 to 1
  • 8.0mm (0.315 inches) Package body width
  • 6.0mm (0.236 inches) Package body length
  • 4 Additional IC center pad contacts
  • 1.3mm (51 mil) pitch
  • DIP pins are round solder tail
  • Compatible SOIC Package Drawing
  • Plastronics 08QN12T18060 Open top socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 600 mils apart
$122.00
8QN51-D6-ZO-P 8 Pin QFN adapter with open top ZIF socket to DIP Pins 8 Pin QFN adapter with open top ZIF socket to DIP Pins
  • For 8 Pins, 4 each on the two shortest sides
  • QFN to DIP pins are wired 1 to 1
  • 8.0mm (0.315 inches) Package body width
  • 6.0mm (0.236 inches) Package body length
  • 4 Additional IC center pad contacts
  • 1.3mm (51 mil) pitch
  • DIP pins are 25 mil square wire-wrap
  • Compatible SOIC Package Drawing
  • Plastronics 08QN12T18060 Open top socket
  • Bottom are square 25 mil wire wrap pins
  • Bottom pins are DIP rows 600 mils apart
$122.00
8SOIC15-D3-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • 6.0mm Leads tip to tip
  • 3.9mm (154 mil) Component body width
  • 1.27mm (50 mil) Pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Bottom pins are 25mil square
  • DIP rows 300 mils apart
$70.00
8SO15-D3-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • For 8 pin SOIC package
  • 6.4mm Leads tip to tip
  • 3.9mm (153 mil) Component body width
  • 5.4mm (213 mils) Body length
  • 1.27mm (50 mil) Pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Replacement ZIF socket is 652B0082211-002
  • Bottom pins are square 25 mil wire wrap
  • DIP rows 300 mils apart
$70.00
8SO15-D6-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • For 8 pin SOIC package
  • 6.4mm Leads tip to tip
  • 3.9mm (153 mil) Component body width
  • 5.4mm (213 mils) Body length
  • 1.27mm (50 mil) Pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Replacement ZIF socket is 652B0082211-002
  • Bottom pins are DIP rows 600 mils apart
$70.00
8SO17-D3-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • For 8 pin SOIC package
  • 6.4mm Leads tip to tip
  • 4.4 (173 mils) Chip body width
  • 5.4mm (213 mils) Body length
  • 1.27mm (50 mil) Pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Replacement ZIF socket is 652B0082211
  • Bottom pins are DIP rows 300 mils apart
$70.00
8SO21-D6-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • For 8 pin SOIC package
  • 7.9mm (311 mil) Leads tip to tip
  • 5.3mm (209 mil) Chip body width
  • 5.3mm (209 mil) Body length
  • 1.27mm (50 mil) Pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Replacement ZIF socket is 652C0082211W003
  • Bottom pins are DIP rows 600 mils apart
$70.00
8SO30-D6-ZO 8 Pin SOIC adapter with open top ZIF socket to DIP Pins 8 Pin SOIC adapter with open top ZIF socket
  • For 8 pin SOIC package
  • 5.3mm (209 mil) Component body width
  • 8.0mm (315 mils) Leads tip to tip
  • 1.27mm (50 mil) pitch
  • Compatible SOIC Package Drawing
  • Open top ZIF socket
  • Replacement ZIF socket is 652C0082211W
  • Bottom pins are DIP rows 600 mils apart
$70.00
8SSO12-D5-ZO-P 8 Pin TSOP SSOP to DIP pin adapter 8 Pin SSOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 8 pin SSOP package
  • Pins are wired one to one
  • 3.0mm (0.118 inch) Component body width
  • 4.9mm (0.193 inch) Leads tip to tip
  • Pitch 0.65mm (25.6 mil)
  • Compatible SOIC Package Drawing
  • ZIF socket is Sensata 656-1082211
  • Bottom pins are 25 mil SQUARE
  • DIP rows are 500 mils apart on 100 mil centers
$75.00
8SSO12-D5-ZO-S 8 Pin TSOP SSOP to DIP pin adapter 8 Pin SSOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 8 pin SSOP package
  • Pins are wired one to one
  • 3.0mm (0.118 inch) Component body width
  • 4.9mm (0.193 inch) Leads tip to tip
  • ZIF socket is Sensata 656-1082211
  • Pitch 0.65mm (25.6 mil)
  • Bottom pins are round solder tail type.
  • DIP rows are 500 mils apart on 100 mil centers
$75.00

Part Number   10 Pin    Price Shopping Cart
10QFN-D6-ZL-P 10 Pin QFN closed top ZIF socket to pins. Pins are wired one to one. 10 Pin QFN closed top ZIF socket to pins. Pins are wired one to one.
  • For 10 pin QFN package
  • Pins are wired one to one
  • 3.0mm (0.118 inch) Square component body
  • Closed top ZIF socket is Plastronics 10QN50S13030
  • Pitch 0.50mm (0.0197 inch)
  • Bottom pin rows are 25 mil square and 600 mils apart on 100 mil centers.
$115.00
10QFN-D6-ZL-S 10 Pin QFN closed top ZIF socket to pins. Pins are wired one to one. 10 Pin QFN closed top ZIF socket to pins. Pins are wired one to one.
  • For 10 pin QFN package
  • Pins are wired one to one
  • 3.0mm (0.118 inch) Square component body
  • Closed top ZIF socket is Plastronics 10QN50S13030
  • Pitch 0.50mm (0.0197 inch)
  • Bottom pin rows are round and 600 mils apart on 100 mil centers.
$115.00
10TO5-D6 10 Pin TO-5 ZIF socket to pins. Pins are wired one to one. 10 Pin To-5 Circular pin adapter with ZIF socket. The socket pad points to pin 10, and pins are wired one to one.
  • For 10 pin TO-5 package components
  • Pins are wired one to one
  • Component pin alignment guides
  • Circular 5.08mm (200 mils) device pin pattern is Sensata 611-1102314
  • Bottom DIP pins are 25 mil square
  • Rows are 600 mils apart and pins are 10 mils apart.
$55.00
10TO5-D6-S 10 Pin TO-5 ZIF socket to pins. Pins are wired one to one. 10 Pin To-5 Circular pin adapter with ZIF socket. The socket pad points to pin 10, and pins are wired one to one.
  • For 10 pin TO-5 package components
  • Pins are wired one to one
  • Component pin alignment guides
  • Circular 5.08mm (200 mils) device pin pattern is Sensata 611-1102314
  • Bottom pins are round 18 mil solder-tail.
  • Rows are 600 mils apart and pins are 10 mils apart.
$55.00
10TS05-D3-ZO-S 10 Pin TSOP closed top ZIF socket to pins. Pins are wired one to one. 10 Pin TSOP adapter with open top ZIF socket. Pins are wired one to one.
  • For 10 pin TSOP package
  • Pins are wired one to one
  • Package width 3.0 (118 mils)
  • Open top ZIF socket is Sensata 656-0102211
  • Pitch 0.5mm (0.020 inch)
  • Bottom pins are round, solder-tail
  • DIP rows are 300 mils apart with pins on 100 mil centers
$55.00
10TS05-D3-ZO-P 10 Pin TSOP closed top ZIF socket to pins. Pins are wired one to one. 10 Pin TSOP adapter with open top ZIF socket. Pins are wired one to one.
  • For 10 pin TSOP package
  • Pins are wired one to one
  • Package width 3.0 (118 mils)
  • Open top ZIF socket is Sensata 656-0102211
  • Pitch 0.5mm (0.020 inch)
  • Bottom pins are 25 mil square wire wrap
  • DIP rows are 300 mils apart with pins on 100 mil centers
$55.00

Part Number   14 Pin    Price Shopping Cart
14D3-D6 14 pin DIP package to DIP wire wrap pins adapter. 14 Pin DIP package to DIP wire wrap pins adapter. Pins are wired one to one.
  • 14 pin DIP package to DIP wire wrap pins adapter.
  • Pins are wired one to one
  • Pitch 0.25mm (100 mil) Standard breadboard spacing
  • Bottom pins are 25 mil square and rows are 600 mils apart
$6.00
14QFN20-D6-ZL-P 14 Pin QFN to DIP pin adapter 14 Pin QFN to DIP pin adapter with closed top ZIF socket. Pins are wired one to one.
  • For 14 pin QFN package
  • Pins are wired one to one
  • 3.0mm (0.118 inch) X 4.00mm (0.157 inch) Component body
  • Pitch 1.27mm (0.050 inch)
  • Compatible QFN IC Package Drawing
  • Bottom pins are 25 mil square and rows are 600 mils apart
$125.00
14SO15-D3-ZO-P 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SOP package
  • Pins are wired one to one
  • 3.9mm (0.154 inch) Component body width
  • 6.0mm (0.236 inch) Leads tip to tip
  • Replacement ZIF socket is 652B0142211-002
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are square and rows are 300 mils apart
$75.00
14SO15-D3-ZO 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SOP package
  • Pins are wired one to one
  • 3.9mm (0.154 inch) Component body width
  • 6.0mm (0.236 inch) Leads tip to tip
  • Replacement ZIF socket is 652B0142211-002
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are round solder-tail, and the rows are 300 mils apart
$75.00
14SO17-D3-ZO-P 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SOP package
  • Pins are wired one to one
  • 4.4mm (0.173 inch) Component body width
  • 6.40mm (0.252 inch) Leads tip to tip
  • Replacement ZIF socket is 652B0142211
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are square and rows are 300 mils apart
$75.00
14SO17-D3-ZO 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SOP package
  • Pins are wired one to one
  • 4.4mm (0.173 inch) Component body width
  • 6.40mm (0.252 inch) Leads tip to tip
  • Replacement ZIF socket is 652B0142211
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are round solder-tail, and the rows are 300 mils apart
$75.00
14SO20-D3-ZO 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SOP package
  • Pins are wired one to one
  • 5.0mm (0.197 inch) Component body width
  • 6.40mm (0.252 inch) Leads tip to tip
  • Replacement ZIF socket is 652B0142211-001
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are square and rows are 300 mils apart
$75.00
14SSO17-D3-ZO 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SSOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SSOP package
  • Pins are wired one to one
  • 4.39mm (0.173 inch) Component body width
  • 6.4mm (0.252 inch) Leads tip to tip
  • Open top ZIF socket is Sensata 676-3140111
  • Pitch 0.65mm (25.6 mil)
  • Bottom pins are round and 300 mils apart
$70.00
14SSO17-D6-ZO 14 Pin TSOP SSOP to DIP pin adapter 14 Pin SSOP to DIP pin adapter with open top ZIF socket. Pins are wired one to one.
  • For 14 pin SSOP package
  • Pins are wired one to one
  • 4.39mm (0.173 inch) Component body width
  • 6.4mm (0.252 inch) Leads tip to tip
  • Open top ZIF socket is Sensata 676-3140111
  • Pitch 0.65mm (25.6 mil)
  • Bottom pins are wire wrap type square and 600 mils apart
$70.00

Part Number   16 Pin    Price Shopping Cart
C16QFN20-D6-ZL-S-P 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package. 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. $215.00
C16QFN20A-D6-ZL-S-P 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package. 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. $215.00
16QFN26-D6-ZL-S-P 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package. 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern.
  • Plastronics 16QF65S14040 clamshell type 16 pin QFN socket
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • 0.65mm (25.6 mil) Pitch device
  • Center pad spring probe
  • For 4x4mm square package
  • 0.65mm (25.6 mil) Pitch device
  • 4.0mm Square Package body width
  • 16 Pin DIP 0.10 inch standard breadboard matrix
  • Pins are wired one-to-one
  • DIP wire wrap rows are 600 mils apart
  • Useful for Atmel ATtiny2313, ATtiny2313V ATmega85V - Microchip Technology PIC18F1230, PIC18F1230
$215.00
C16QFN26-D6-ZL-S-P 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package. 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern.
  • Plastronics 16QF65S14040 clamshell type 16 pin QFN socket
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • 0.65mm (25.6 mil) Pitch device
  • Center pad spring probe
  • For 4x4mm square package
  • 0.65mm (25.6 mil) Pitch device
  • 4.0mm Square Package body width
  • 16 Pin DIP 0.10 inch standard breadboard matrix
  • Pins are wired one-to-one
  • DIP wire wrap rows are 600 mils apart
  • Useful for Atmel ATtiny2313, ATtiny2313V ATmega85V - Microchip Technology PIC18F1230, PIC18F1230
$215.00
16QFN39-D6-ZL-P 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package 16 QFN adapter with hinge lid test ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 4x4mm square, 0.65mm (25.6 mil) pitch package
  • Plastronics 16QN10S16060 clamshell type 16 pin QFN socket.
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • 1.0mm (39.4 mil) Pitch device
  • Center pad spring probe
  • 6.0mm (236 mil) Square Package body width
  • 16 Pin DIP 0.10 inch standard breadboard matrix
  • Pins are wired one-to-one starting at the top center QFP pad
  • DIP row wire wrap pins, 600 mils apart
$215.00
16QFN20-3X5-D6-ZO 16 QFN adapter with open top ZIF QFP socket on a .1 inch DIP male pins breadboard pattern. For 3.3mm square, 0.5mm pitch package. 16 QFN adapter with open top ZIF QFP socket on a 0.1 inch, 100 mil, DIP male pins breadboard pattern. For 3.3mm square, 0.5mm pitch package. $215.00
16SO15-D3-ZO-S 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin SOIC adapter with open top ZIF socket. Pins are wired one to one.
  • For 16 pin SOIC package
  • Pins are wired one to one
  • 5.0mm (0.197 inch) Component body width
  • 6.8mm (0.268 inch) Leads tip to tip
  • Open top ZIF socket is Sensata 652B0162211-001
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are 18 mil,round solder 300 mils apart
$70.00
16SO15-D3-ZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin SOIC adapter with open top ZIF socket. Pins are wired one to one.
  • For 16 pin SOIC package
  • Pins are wired one to one
  • 5.0mm (0.197 inch) Component body width
  • 6.8mm (0.268 inch) Leads tip to tip
  • Open top ZIF socket is Sensata 652B0162211-001
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are 25 mil square 300 mils apart
$70.00
16SO21-D3-ZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin SOIC adapter with open top ZIF socket. Pins are wired one to one.
  • 16 Pins SOIC Package
  • 5.3mm (209 mils) Package body width
  • 7.7mm (303 mils) Leads tip to tip
  • 1.27mm (50 mil) Pitch device
  • Open top ZIF socket is Sensata Yamaichi IC189-0162-019
  • Pitch 1.27mm (0.050 inch)
  • Bottom pins are 25 mil square 300 mils apart
$145.00
16SO30-D3-EZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. Pins are wired one to one.
  • 7.5mm (295 mil) Package body width
  • 10. 3mm (406 mil) Leads Tip to tip
  • 10.45mm (411 mil) Package body length
  • 1.27mm (50 mil) pitch
  • Plug-in replaceable socket. Uses socket number 652D0162211E202
  • Bottom pins are square, wire wrap type, and rows are 300 mils apart
$70.00
16SO30-D6-EZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin ZIF socket adapter for devices in 411 mil wide body SOIC packages. Pins are wired one to one.
  • 16 Pins SOIC Package
  • 10. 3mm (406 mil) Leads Tip to tip
  • 10.45mm (411 mil) Package body length
  • 1.27mm (50 mil) pitch
  • Plug-in replaceable socket. Uses socket number 652D0162211E202
  • Bottom pins are round solder tail, and rows are 600 mils apart
$70.00
16SO30NR-D3-ZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. The sockets do not have IC body alignment rails. Pins are wired one to one.
  • 16 Pins SOIC Package
  • No IC alignment rails inside the socket. Fits odd sized or extra IC wide plastic body.
  • 7.6mm (299 mils) Package width
  • 10.2mm (402 mils) Leads tip to tip
  • 10.50 (413 mils) Body length
  • 1.27mm (50 mil) Pitch
  • Plug-in replaceable socket. Uses socket number 652-0162211-001
  • Bottom pins are rows are 300 mils apart
$70.00
16SSO17-D6-ZO 16 SOIC adapter with open top ZIF socket. Pins are wired one to one. 16 Pin SOIC socket to DIP adapter for SOIC packages. Pins are wired one to one.
  • For 16 pin SOIC package
  • Pitch 0.65mm (25.6 mils)
  • 4.39mm (173 mil) Component body width
  • 5.0mm (100 mil) body length
  • 6.25 to 6.56mm (0.246 to 0.258 inch) Leads Tip to tip
  • Open top ZIF socket
  • Replacement ZIF socket is 676-3160111
  • Bottom pins are rows are 600 mils apart on 100 mil centers.
$70.00
16SSO21-D3-ZO 16 pin SSOP test socket to DIP & proto board adapter 16 Pin SSOP and TSSOP to DIP rows adapter for devices in 209-mil, 5.3mm wide, 16 lead SSOP package.
  • For 16 pin SSOP package
  • 5.3mm (0.209 inch)Chip body width
  • 7.8mm (0.307 inch)Leads tip to tip
  • 6.2mm (0.244 inch)Body length
  • 0.65mm (25.6 mil) Pitch
  • Wired one-to-one
  • Open top ZIF socket is Sensata 656C1162211
  • Bottom pins are DIP rows 300 mils apart
  • Compatible with standard bread board 0.1 inch holes
$70.00

Part Number   20 Pin    Price Shopping Cart
20PL-D6-ZAD 20 Pin PLCC adapter for PLCC packages. Dead-bug insertion autoeject socket. 20 Pin PLCC adapter for PLCC packages. Dead-bug insertion autoeject socket, i.e. The package is inserted upside down with the cut corner to the right. Accepts plastic packages only. This adapter is wired one-to-one
  • Dead Bug (Legs up) Insertion
  • Plastic PLCC Package Type
  • 20 Pins PLCC to 20 Pin DIP
  • Pins are wired one-to-one
  • Open top ZIF socket is Yamaichi IC120-0204-205
  • DIP rows are 600 mils apart
$145.00
C20QFN20-D6-ZL-P 20 pad QFN MLF adapter is wired one to one. QFN pin 1 is at the top of the pads on the left side. 20 pad QFN MLF adapter is wired one to one. QFN pin 1 is at the top center of the pads.
  • For 20 pad QFN MLF package
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • QFN pin 1 is at the top of the pads on the left side.
  • 4.0 x 4.0mm (0.157 x 0.157 inch) Component body width
  • DIP to Socket pins are wired 1 to 1. (DIP pin 1 to QFN pin 1, DIP pin 2 to QFN pin 2, and so on to 20
  • Pitch 0.5mm
  • Closed top ZIF socket
  • Bottom pins are square 25 mil wire-wrap 600 mils apart
$220.00
20QFN20-D6-ZL-P 20 pad QFN MLF adapter is wired one to one. QFN pin 1 is in the center of the top row of of the pads. 20 pad QFN MLF adapter is wired one to one. QFN pin 1 is in the center of the top row of of the pads.
  • For 20 pad QFN MLF package
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • 4.0 x 4.0mm (0.157 x 0.157 inch) Component body width
  • DIP to Socket pins are wired 1 to 1. (DIP pin 1 to QFN pin 1, DIP pin 2 to QFN pin 2, and so on to 20
  • Socket center pin is accessible for signal connection.
  • Pitch 0.5mm
  • Closed top ZIF socket is Plastronics 20QN50S14040
  • Bottom pins are 25 mil square wire wrap and DIP rows are 600 mils apart.
$220.00
20QFN26-D6-ZL-P-L 20 Pin QFN Closed top adapter for 20 lead QFN packages to DIP pin adapter. 20 pad QFN MLF adapter is wired one to one.
  • For 20 pad QFN MLF package
  • PIN 1 Location & Compatible QFN IC Package Drawing and connetion.
  • 5.0mm Square component body width
  • QFN pin 1 center top row is connected to DIP pin 20 QFN pin 2 to DIP pin 1 and so on to pin 19
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$220.00
20QFN26-D6-ZL-P-R 20 Pin QFN Closed top adapter for 20 lead QFN packages. 20 pad QFN MLF adapter is wired one to one.
  • For 20 pad QFN MLF package
  • PIN 1 Location & Compatible QFN IC Package Drawing and connetion.
  • 5.0mm Square component body width
  • QFN pin 1 center top row is connected to DIP pin 1 and so on to pin 20
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$220.00
20SO21-D6-ZL   20 Pin SSOP Closed top adapter for 20 lead SSOP packages. This adapter is wired one-to-one. 20 Pin SOIC Closed top adapter for 20 lead SOIC packages. Socket and DIP pins are wired one-to-one.
  • 20 Pin SOIC Package type
  • Socket is Enplas FP-20-1.27-0.6
  • 6.64mm (261 mil) Package width
  • 10.59mm (417 mil) Maximum Leads tip to tip
  • 7.15mm (281 mil) Outside lead J-bend to J-bend
  • 1.27mm (50 MIL) Pitch pins
  • Pins are wired one-to-one
  • DIP rows are 600 mils apart
$80.00
20SO30A-D3-ZO 20 Pin ZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages. 20 PinZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages.
  • For 20 pin SOIC package
  • 7.55mm (300 mil) Body width
  • 10.4mm (409 mil) Leads tip to tip
  • 13.11mm (516 mil) Body length
  • 1.27mm Pitch
  • Open top ZIF socket
  • Bottom pins are 300 mils apart
$80.00
20SO30A-D6-ZL 20 Pin ZIF socket adapter for devices in 7.6mm (300 mil) wide body SOIC packages. 20 PinZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages.
  • For 20 pin SOIC package
  • 7.6mm (300 mil) Body width
  • 10.2mm (401 mil) Leads tip to tip
  • 13.11mm (516 mil) Body length
  • 1.27mm Pitch
  • Open top ZIF socket
  • Bottom pins are 25 mil square.
  • DIP rows are 600 mil apart
$80.00
20SSO17-D6-ZL 20 Pin SSOP Closed top adapter for 20 lead SSOP packages. This adapter is wired one-to-one. 20 Pin SSOP Closed top adapter for 20 lead SSOP packages. This adapter is wired one-to-one.
  • 20 Pin SSOP Package type
  • 173 mil Package width
  • 0.65mm (25.6 mil) Pitch pins
  • Pins are wired one-to-one
  • Closed top ZIF socket is Enplas FP-20-0.65-01
  • DIP rows are 600 mils apart
$75.00
20SSO17-D6-ZO 20 Pin SSOP and TSSOP adapter. The adapter accepts 173-mil, 4.4mm wide SSOP packages This adapter is wired one-to-one. 20 Pin SSOP and TSSOP adapter accepts 173 mil, 4.4mm wide SSOP packages This adapter is wired one-to-one.
  • For 20 pin SSOP package
  • 173 mil wide component body
  • Pitch 0.65mm
  • Open top ZIF socket
  • Bottom pins are DIP rows 600 mils apart
  • Compatible with EE Tools and Needham's EMP10, EMP20, EMP30 programmers
  • Serial-Memory
    24128-B, 24256-B, 24AA00, 24AA64, 24C00, 24C01, 24C01A, 24C02, 24C02A, 24C02C, 24C04, 24C08, 24C16, 24C32, 24C64, 24LC00, 24LC01B, 24LC024, 24LC025, 24LC02B, 24LC16B, 24LC64, 24LCS52, 24LCS61, 24LCS62, 25AA040, 25AA640, 25C040, 25C640, 25LC040, 25LC640, 32C02, 93C06, 93C46, 93C46A, 93C46B, 93C56, 93C57, 93C66, 93C86, 93LC46A, 93LC46B, 93LC56A, 93LC56B, 93LC66A, 93LC66B, 93S46, 93S56, 93S66, 95010, 95020, 95040, 95080, 95128, 95160, 95256, 95320, 95640
$75.00
20SSO21-D3-ZO 20 pin SSOP test socket to DIP & proto board adapter 20 Pin SSOP and TSSOP to DIP rows adapter for devices in 208-mil, 5.2mm wide, 20 lead SSOP package.
  • For 20 pin SSOP package
  • 5.3mm (0.208 inch) Chip body width
  • 7.8mm (0.307 inch) Leads tip to tip
  • 7.2mm (0.283 inch) Body length
  • 0.65mm (25.6 mil) Pitch
  • Wired one-to-one
  • Open top ZIF socket ZIF socket is 656C1202211
  • Bottom DIP are square wire wrap pins
  • DIP rows 300 mils apart
  • Compatible with standard bread board 0.1 inch holes
$75.00
20SSO21-D3-ZO-S 20 pin SSOP test socket to DIP & proto board adapter 20 Pin SSOP and TSSOP to DIP rows adapter for devices in 208-mil, 5.2mm wide, 20 lead SSOP package.
  • For 20 pin SSOP package
  • 5.3mm (0.208 inch) Chip body width
  • 7.8mm (0.307 inch) Leads tip to tip
  • 7.2mm (0.283 inch) Body length
  • 0.65mm (25.6 mil) Pitch
  • Wired one-to-one
  • Open top ZIF socket ZIF socket is 656C1202211
  • Bottom DIP are round solder-tail pins
  • DIP rows 300 mils apart
  • Compatible with standard bread board 0.1 inch holes
$75.00

Part Number   24 Pin    Price Shopping Cart
24QFN16-D6-ZL-S 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired AFN signal to DIP equivalent signal.
  • For 24 pad QFN MLF package
  • 4.0 X 4.0mm component body
  • Pitch 0.4mm
  • Closed top clamshell ZIF socket
  • DIP rows are 600 mils apart
  • DIP pins are round solder tail type
$270.00
24QFN16-D6-ZLS-P 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired signal connection one to one.
  • For 24 pad QFN MLF package
  • 4.0 X 4.0mm component body
  • Pitch 0.4mm
  • Closed top clamshell ZIF socket
  • DIP rows are 600 mils apart
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$270.00
C24QFN20-D3-ZL-P 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired signal connection one to one. $270.00
C24QFN20-D6-ZL-P 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired signal connection one to one. $270.00
C24QFN20-D6-ZL-P 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired signal connection one to one. $270.00
24QFN20-D6-ZL-P 24 pin QFN MLF socket to DIP & proto board adapter 24 pad QFN MLF adapter is wired signal connection one to one.
  • For 24 pad QFN MLF package
  • 4.0 X 4.0mm component body
  • Pitch 0.5mm
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$270.00
24QSO-D3-ZO   24 pin QSOP test socket to DIP & proto board adapter 24 Pin ZIF socket adapter for devices in 4.4MM wide body SOP packages. Generic one to one wiring.
  • For 24 pin QSOP package
  • 3.9mm (154 mil) Component body width
  • 6.0mm (236 mil) Leads tip to tip
  • Pitch 0.65mm (25.6 mil)
  • Open top ZIF Sensata 656-4242211 socket
  • Bottom DIP pins are round solder tail 300 mils apart
$85.00
24QSO30A-D3-ZO   24 Pin ZIF socket adapter for devices in 4.4MM wide body SOP packages. Generic one to one wiring.
  • For 24 pin QSOP package
  • 4.4mm Component body width
  • 6.4mm Leads tip to tip
  • Pitch 0.65mm (25.6 mil)
  • Open top ZIF Enplas OTS24(28)0.635-02 socket
  • Bottom pins are round solder tail, 600 mils apart
$85.00
24SO30A-D3-ZO 24 Pin ZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages. 24 Pin ZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages.
  • For 24 pin SOIC package
  • 7.55mm (297 mil) Body width
  • 10.47mm (413 mil) Leads tip to tip
  • 15.65mm (616 mil) Body length
  • 1.27mm (50 mil) Pitch
  • Replacement open top Sensata ZIF socket is 652D0242211
  • Open top Sensata 652D0242211 ZIF socket
  • Bottom pins are round solder tail 300 mils apart
$85.00
24SO30A-D6-ZO 24 Pin ZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages. 24 PinZIF socket adapter for devices in 7.55mm (300 mil) wide body SOIC packages.
  • For 24 pin SOIC package
  • 7.55mm (297 mil) Body width
  • 10.47mm (413 mil) Leads tip to tip
  • 15.65mm (616 mil) Body length
  • 1.27mm (50 mil) Pitch
  • Replacement open top Sensata ZIF socket is 652D0242211
  • Bottom pins are round solder tail, 600 mils apart
$85.00
24SSOS15-D6-ZO 24 Pin SSOP ZIF socket adapter for devices in 6.0mm (154 mil) wide body packages. Generic adapter, pins are wired 1 to 1, DIP pin to socket pin. 24 Pin SSOP ZIF socket adapter for devices in 6.0mm (154 mil) wide body packages. Generic adapter, pins are wired 1 to 1, DIP pin to socket pin.
  • For 24 pin SOIC package
  • 3.9mm (154 mil) Body width
  • 6.0mm (236 mil) Leads tip to tip
  • 8.65mm (341 mil) Body length
  • 0.65mm (26 mil) Pitch
  • Open top Sensata 656J1242211TP ZIF socket
  • Bottom pins are round solder tail, 600 mils apart
$80.00
24SSOS17-D6-ZO 24 Pin TSOP Type 1 package socket to DIP. Pins are wired 1 to 1 24 Pin Pin TSOP Type 1 package socket to DIP. Pins are wired 1 to 1. Generic adapter, pins are wired 1 to 1.
  • For 24 pin TSOP Package Type 1
  • Compatible SSOP IC Package Drawing
  • 4.4mm (173 mils) Package body width
  • 6.4 mm (252 mils) Leads Tip to tip
  • 8.4mm (331 mils) Package body length
  • 0.65mm (25.6 mil) pitch
  • Plug-in replaceable socket. Uses socket number OTS-24-0.65-01
  • Bottom DIP pins are 25 mil square wire wrap, 600 mils apart
$80.00
24SSO21-D3-ZO 24 Pin SSOP Type 1 package socket to DIP. Pins are wired 1 to 1 24 Pin Pin TSOP Type 1 package socket to DIP. Pins are wired 1 to 1. Generic adapter, pins are wired 1 to 1.
  • For 24 pin SSOP Package
  • Compatible SSOP IC Package Drawing
  • 5.3mm (0.209 inch) Package body width
  • 0.65mm (25.6 mil) pitch
  • 7.8mm (0.307 inch)Tip to tip
  • 7.2mm (0.283 inch)Body length
  • Bottom DIP pins are 25 mil square wire wrap, 300 mils apart
$80.00
24SSO21-D6-ZO 24 Pin SSOP Type 1 package socket to DIP. Pins are wired 1 to 1 24 Pin Pin TSOP Type 1 package socket to DIP. Pins are wired 1 to 1. Generic adapter, pins are wired 1 to 1.
  • For 24 pin SSOP Package
  • Compatible SSOP IC Package Drawing
  • 5.3mm (0.209 inch) Package body width
  • 0.65mm (25.6 mil) pitch
  • 7.8mm (0.307 inch)Tip to tip
  • 7.2mm (0.283 inch)Body length
  • Bottom DIP pins are 25 mil square wire wrap, 600 mils apart
$80.00

Part Number   28 Pin    Price Shopping Cart
28DIP-ZIF-D3 28 pin DIP ZIF socket to 28 wire-wrap pins wired one to one. 28 pin socket to 28 pin DIP adapter wired one to one.
  • 28 pin ZIF DIP socket to 28 wire-wrap pins
  • Wired 1 to 1
  • Bottom pins are 25 mil square and the DIP rows are 300 mils apart
$140.00
28D6-28PL 28 pin DIP socket to 28 pin PLCC Plug adapter wired one to one. 28 pin socket to 28 pin PLCC Plug adapter wired one to one.
  • 28 pin DIP socket to 28 pin PLCC Plug
  • Wired 1 to 1 DIP to PLCC
  • 450 mil square PLCC body width
  • 490 mil standard PLCC tip to tip
  • PLCC Pitch 50 mil (1.27mm)
  • Bottom pins are round for solid contact without stressing the PLCC socket
$40.00
28PL-D9-ZAL 28 pin PLCC socket to 28 DIP pins adapter. 28 pin DIP socket to 28 pin PLCC Plug
  • 28 pin PLCC socket to 28 DIP pins
  • Plug-in Replaceable Auto eject PLCC socket IC120-0284-108
  • Wired 1 to 1 DIP to PLCC
  • PLCC Pitch 50 mil (1.27mm)
  • Bottom pins are 25 mil square wire wrap
$120.00
28D6-32PL 28 pin DIP to 32 pin PLCC socket. PLCC pins 1, 12, 17, 26 not connected. 28 pin DIP to 32 pin PLCC socket. PLCC pins 1, 12, 17, 26 not connected.
  • 28 pin PLCC socket to 32 pin rectangular PLCC plug.
  • PLCC to DIP connection list
  • For rectangular 32 pin PLCC package
  • PLCC Pitch 50 mil (1.27mm)
$45.00
28QFN16-D6-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • DIP pin 1 is connected to the QFN top left side contact
  • 4.0mm x 4.0mm Body width
  • Pitch 0.4mm (16 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
C28QFN16-D6-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • DIP pin 1 is connected to the QFN left side row top contact
  • 4.0mm x 4.0mm Body width
  • Pitch 0.4mm (16 mil)
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
28QFN16-D6-ZL-PC 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • DIP pin 1 is connected to the QFN top side row, left contact
  • 4.0mm x 4.0mm Body width
  • Pitch 0.4mm (16 mil)
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
C28QFN20-D6-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • DIP pin 1 is connected to the QFN top left side contact
  • 5.0mm x 5.0mm Body width
  • Pitch 0.5mm (20 mil)
  • PIN 1 Location & Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
28QFN26L-D3-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • 6.0mm Component body width
  • QFN pin 25, center QFN contact on the chip side facing adapter PCB pins DIP 1 and DIP 20 is connected to pin DIP 1. All other pins are one to one.
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 300 mils apart
$240.00
28QFN26R-D3-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • 6.0mm Component body width
  • QFN pin 25, center QFN contact on the chip side facing adapter PCB pins DIP 1 and DIP 20 is connected to pin DIP 28. All other pins are one to one.
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 300 mils apart
$240.00
28QFN26L-D6-ZL-P 28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • 6.0mm Component body width
  • QFN pin 1 top row center is connected to DIP pin 1 and so on to pin 28
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
28QFN26R-D6-ZL-P  28 Pin QFN to DIP closed top socket adapter. 28 pad QFN MLF adapter is wired one to one.
  • For 28 pad QFN MLF package
  • 6.0mm Component body width
  • QFN pin 1 DIP 1 is connected to DIP pin 28. All other pins are one to one.
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$240.00
28QSO-D6-ZO 28 Pin QSOP to DIP pins adapter. Generic adapter wired one-to-one. 28 Pin QSOP to DIP adapter for 28 lead QSOP package. Generic adapter wired pins one to one.
  • For 28 pin QSOP package <
  • 3.94mm Package body width
  • 6.0mm Leads Tip to tip
  • 9.7mm Body length
  • 0.635mm (0.025 inch) pitch
  • Bottom pins are 25 mil square wire-wrap and DIP rows are 600 mils apart
$145.00
28SSO17-D6-ZO 28 Pin SSOP programming adapter for 173-mil wide, 28 lead SSOP package. Generic adapter wired one-to-one. 28 Pin SSOP to DIP adapter for 173-mil wide, 28 lead SSOP package. Generic adapter wired one-to-one.
  • For 28 pin SSOP package
  • 173 mil wide component body
  • Pitch 0.65mm
  • Open top ZIF socket
  • Bottom pins are DIP rows 600 mils apart
  • Compatible with EE Tools and Needham's EMP10, EMP20, EMP30 programmers
$145.00
28SSO21-D3-ZO-P 28 Pin ZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring 28 PinZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring.
  • For 28 pin SSOP package
  • 5.7mm max(209 mil) Component body width
  • 7.8mm max (307 mil) Tip to tip
  • 0.65mm (25.6 mil) Pitch
  • Open top ZIF socket
  • Bottom pins are 25 mil square wire-wrap and DIP rows are 300 mils apart
$145.00
28SSO21-D3-ZO-S 28 Pin ZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring 28 PinZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring.
  • For 28 pin SSOP package
  • 5.7mm max(209 mil) Component body width
  • 7.8mm max (307 mil) Tip to tip
  • 0.65mm (25.6 mil) Pitch
  • Open top ZIF socket
  • Bottom pins are round solder tail and DIP rows are 300 mils apart
$145.00
28SSO21-D6-ZO 28 Pin ZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring. 28 PinZIF socket adapter for devices in 5.7mm max wide body SSOP packages. Generic one to one wiring.
  • For 28 pin SSOP package
  • 5.7mm max(209 mil) Component body width
  • 7.8mm max (307 mil) Tip to tip
  • 0.65mm (25.6 mil) Pitch
  • Open top ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$145.00
28TS14-D6-ZO 28 Pin TSOP Type 1 Package to DIP. Generic one to one wiring. 28 Pin TSOP Type 1 Package to DIP. Generic one to one wiring.
  • For 28 pin TSOP package
  • TSOP Type 1 Package Type
  • 13.4mm (528 mils) Leads Tip to tip
  • 8.0mm (315 mils) Package width
  • 0.55mm (22 mils) pitch
  • TSOP pin 1 is in the center of one side.
  • DIP to TSOP pins are wired 1 to 1
  • Replacement ZIF socket is 648-1282211-A01
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$145.00

Part Number   32 Pin    Price Shopping Cart
32DIP-ZIF-D3 32 pin DIP ZIF socket to 28 wire-wrap pins wired one to one. 32 pin socket to 32 pin DIP adapter wired one to one.
  • 32 pin ZIF DIP socket to 32 wire-wrap pins
  • Wired 1 to 1
  • Bottom pins are 25 mil square and the DIP rows are 300 mils apart
$140.00
32PL-D6-ZO 32 Pin PLCC to 32 pin DIP. This adapter is wired one-to-one. 32 Pin PLCC to 32 pin DIP. This adapter is wired one-to-one.
  • 32 Pin PLCC to 32 Pin DIP
  • Compatible PLCC Package Drawing
  • Live bug programming.
  • The socket is mounted with plug-in replaceables. The replacement ZIF auto-eject socket is a Yamaichi IC120-0324-309
  • DIP rows are 600 mils apart
  • DIP pins are 25 mil square wire wrap
  • Wired one-to-one from DIP pin 1 to PLCC pin 1 & so on to 32.
  • Compatible with any programmer supporting 1 to 4Mb EPROM and flash memories, etc.
$170.00
C32QFN20-D6-ZO-P 32 pad Open top to DIP QFN MLF adapter 32 pad Open top QFN MLF to DIP adapter
  • For 32 pad QFN MLF package
  • 5.0mm (0.197 inch) Component body width
  • Socket is 32LQ50S15050 open top ZIF socket.
  • 5.0mm (0.197 inch) Component body width
  • Pitch 0.5mm (0.20 inch)
  • Open top ZIF sockets
  • Connections - QFN top left contact to DIP pin 1
  • Bottom DIP pins are 25 mil square wire-wrap
  • DIP rows are 600 mils apart
$240.00
C32QFN20-D6-ZO-S 32 pad Open top QFN MLF to DIP adapter 32 pad Open top QFN MLF to DIP adapter
  • For 32 pad QFN MLF package
  • 5.0mm (0.197 inch) Component body width
  • Socket is 32LQ50S15050 open top ZIF socket.
  • 5.0mm (0.197 inch) Component body width
  • Pitch 0.5mm (0.20 inch)
  • Open top ZIF sockets
  • Connections - QFN top left contact to DIP pin 1
  • Bottom DIP pins are 18 mil round solder tail
  • DIP rows are 600 mils apart
$240.00
32QFN20-D6-ZL-P 32 pad QFN MLF closed top adapter. 32 padQFN MLF closed top adapter
  • For 32 pad QFN MLF package
  • 5.0mm (0.197 inch) Component body width
  • Socket is 32QN50S15050 closed top ZIF socket.
  • 5.0mm (0.197 inch) Component body width
  • Pitch 0.5mm (0.20 inch)
  • Closed top clamshell ZIF socket
  • Connections- QFN top left contact to DIP pin 5
  • Bottom DIP pins are square wire wrap
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$270.00
32QFN20-D6-ZL-S 32 pad QFN MLF closed top adapter. 32 pad QFN MLF adapter
  • For 32 pad QFN MLF package
  • 5.0mm (0.197 inch) Component body width
  • Socket is 32QN50S15050 closed top ZIF socket.
  • 5.0mm (0.197 inch) Component body width
  • Pitch 0.5mm
  • Closed top clamshell ZIF socket
  • Connections- QFN top left contact to DIP pin 5
  • Bottom pins are 18 mil round solder pins and DIP rows are 600 mils apart
$270.00
32QFN26-D3-ZL-S 32 Contact Generic QFN MLF programming adapter for devices in 0.65mm pitch 32-lead QFN MLF package. 32 Contact Generic QFN MLF programming adapter for devices in 0.65mm pitch 32-lead QFN MLF package. This QFN adapter has 300 mil wide DIP plug with 18 mil round, solder-tail pins for plugging into 300 mil wide production DIP sockets or 0.1 inch pattern standard breadboards.
  • 32 Pins PLUS Center spring probe
  • Compatible IC drawing
  • 0.65mm (25.6 mil) Pitch device
  • 7.0 x 7.0mm (0.276 x 0.276 inch) Body
  • QFN Top center pin 1 connected to DIP pin 1
  • Clamshell ZIF socket
  • DIP pins are 18 mil round that are 300 mils apart
$270.00
32QFN26-D6-ZL-P 32 pad QFN MLF adapter is wired one to one. 32 pad QFN MLF adapter is wired one to one.
  • For 32 pad QFN MLF package
  • 7.0mm (0.276 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$270.00
32QFN26-D6-ZL-PS 32 pad QFN MLF adapter is wired one to one. 32 pad QFN MLF adapter is wired one to one.
  • For 32 pad QFN MLF package
  • 7.0mm (0.276 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • Closed top clamshell ZIF socket
  • Bottom pins are round solder-tail and DIP rows are 600 mils apart
$270.00
32QFS31-D3-ZO 32 QFP, TQFP adapter is wired one to one. 32 pad QFP, TQFP adapter is wired one to one.
  • For 32 pin QFP TQFP package
  • 7.0mm (0.276 inch) Component body width
  • Pitch 0.8mm (31 mil)
  • Open top ZIF socket
  • Socket plugs in, and Replacement ZIF socket is 3007-032-6-07
  • Bottom pins are round solder-tail and DIP rows are 300 mils apart
$185.00
32SOJ40-D6-ZO 32 Pin ZIF socket adapter for 32 pin SOJ packages. Generic one to one wiring. 32 Pin ZIF socket adapter socket adapter for 32 pin SOJ packages. Generic one to one wiring.
  • For 32 pin SOJ package
  • SOJ Package Type
  • 1.27mm Pitch device
  • Live bug - Leads down orientation
  • 10.9mm Leads Tip to tip to outside face of the J lead
  • Replaceable open top socket is Yamaichi no. IC107-3204-G
  • Bottom pins are round solder tail.
  • DIP Pin rows 600 mils apart
$285.00
32SO30-D6-ZO 32 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. Generic one to one wiring. 32 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. Generic one to one wiring.
  • For 32 pin SOIC package
  • 300 mil Component body width
  • Replaceable open top socket is Sensata no. 652D0322211
  • Bottom pins are square wire wrap.
  • DIP Pin rows 300 mils apart
$145.00
32SO30-D3-ZO-S 32 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. Generic one to one wiring. 32 Pin ZIF socket adapter for devices in 300 mil wide body SOIC packages. Generic one to one wiring.
  • For 32 pin SOIC package
  • 300 mil Component body width
  • Open top ZIF socket
  • DIP pins are round 18 mil diameter solder tail
  • DIP Pin rows are 300 mils apart
$145.00
32SO42-D3-ZO-S 32 Pin ZIF TSOP to round DIP pins for production sockets. Generic one to one wiring adapter. 32 Pin ZIF TSOP to round DIP pins for production sockets. Generic one to one wiring adapter.
  • For 32 pin SOP package
  • 11.0mm (433 mils) Body width
  • 14.04mm (551 mils) Leads tip to tip
  • 1.27mm (50 mil) Pitch
  • Replacement ZIF socket is 652F0322211
  • Bottom pins are round solder tail and DIP rows are 300 mils apart
$145.00
32SO42-D3-ZO 32 Pin ZIF TSOP to square DIP pins. Generic one to one wiring adapter. 32 Pin ZIF TSOP to square DIP pins. Generic one to one wiring adapter.
  • For 32 pin SOP package
  • 11.0mm (433 mils) Body width
  • 14.04mm (551 mils) Leads tip to tip
  • 1.27mm (50 mil) Pitch
  • Replacement ZIF socket is 652F0322211
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$145.00
32SO42-D6-ZL 32 Pin ZIF socket adapter for devices in 425 mil wide body SOP packages. Generic one to one wiring. 32 Pin ZIF socket adapter for devices in 425 mil wide body SOP packages. Generic one to one wiring.
  • For 32 pin SOP package
  • Pitch 1.27mm (50 mil)
  • 10.8mm (425 mil) component body width
  • 14.0mm (551 mils) tip to tip
  • Closed top clamshell ZIF socket
  • Bottom pins are round, 18 mil diameter, solder-tail and DIP rows are 600 mils apart
$145.00
32SO42-D6-ZO ZIF TSOP to DIP generic one to one wiring adapter. For 20 mm Leads tip to tip leads. 32 Pin ZIF SOP to DIP generic one to one wiring adapter. For 20 mm Leads tip to tip leads.
  • For 32 pin TSOP package
  • 11.0mm (433 mils) Body width
  • 14.04mm (551 mils) Leads tip to tip
  • 1.27mm (50 mil) Pitch
  • Replacement ZIF socket is 652F0322211
  • Bottom pins are square and DIP rows are 600 mils apart
$145.00
32SO46-D4-ZL-P ZIF Dead bug SOP to DIP generic one to one wiring adapter. For 14.2mm tip to tip leads. 32 Pin ZIF SOP to DIP generic one to one wiring adapter. Dead bug part placement.
  • For 32 pin SOP package
  • Dead bug socket
  • 11.6mm (456 mils) Body width
  • 14.2mm (559 mils) Leads tip to tip
  • 1.27mm (50 mil) Pitch
  • ZIF socket is an Enplas FP32-1.27-10
  • Bottom pins are square and DIP rows are 400 mils apart
$185.00
32TS14-D6-Z0 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. For 14mm tip to tip leads. 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. For 14mm Leads tip to tip leads.
  • For 32 pin TSOP type 1 package
  • 8.0mm (315 mils)Package width
  • 14.0mm (551 mils) Leads tip to tip
  • 0.50mm (19.7 mil) Pitch
  • Open top 648A0322211-A01 Sensata socket
  • Bottom pins are square and DIP rows are 600 mils apart
  • Compatible TSOP Package Type
$145.00
32TS20-D6-ZO-S 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. For 20mm tip to tip leads. 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. DIP pins are round solder tail. For 20mm Leads tip to tip leads.
  • For 32 pin TSOP type 1 package
  • 8.0mm (315 mils)Package width
  • 20.0mm (787 mils) Leads tip to tip
  • 8.0mm (315 mils)Package width
  • 18.4 (724 mils) Package length
  • 0.50mm (0.020") pitch
  • Bottom pins are round solder pin and DIP rows are 600 mils apart
$145.00
32TS20-D6-ZO 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. For 20mm tip to tip leads. 32 Pin ZIF TSOP type 1 socket to DIP generic one to one wiring adapter. DIP pins are 25 mil square. For 20mm Leads tip to tip leads.
  • For 32 pin TSOP type 1 package
  • 8.0mm (315 mils)Package width
  • 20.0mm (787 mils) Leads tip to tip
  • 8.0mm (315 mils)Package width
  • 18.4 (724 mils) Package length
  • 0.50mm (0.020") pitch
  • Bottom pins are square and DIP rows are 600 mils apart
$145.00

Part Number   36 Pin    Price Shopping Cart
36TS2-D3-ZO 36 Pin TSOP Type 1 socket to 36 pin DIP adapter. Connections are wired pin to pin all pins. 36 Pin TSOP Type 2 socket to 36 pin DIP adapter. Connections are wired pin to pin all pins.
  • For 36 Pin TSOP Type 2 to DIP
  • 10.31mm ( 406 mils) IC Tip-to-Tip
  • 7.52mm (926 mil) IC body width
  • 0.8mm (32 mil) IC pitch
  • Square wire wrap 25 mil square DIP pins mounted on 100 mil centers.
  • DIP rows are 300 mils apart.
$145.00

Part Number   38 Pin    Price Shopping Cart
38TS06-D6-ZO 38 Pin TSOP Type 1 socket to 38 pin DIP adapter. Connections are wired pin to pin all pins. 38 Pin TSOP Type 1 socket to 38 pin DIP adapter. Connections are wired pin to pin all pins.
  • For 38 Pin TSOP Type 1 to DIP
  • 4.40mm (170 mil) Chip body width
  • 6.4mm (250 mil) IC leads Tip to Tip
  • 0.50mm (20 mil) IC pitch
  • Square wire wrap 25 mil square DIP pins mounted on 100 mil centers.
  • DIP rows are 600 mils apart.
$145.00

Part Number   40 Pin    Price Shopping Cart
40QFN16-D6-ZL-P 40 pad QFN MLF adapter is wired one to one. 40 pad QFN MLF adapter is wired one to one. $320.00
40QFN16-D6-ZL-S 40 pad QFN MLF adapter is wired one to one. 40 pad QFN MLF adapter is wired one to one. $320.00
C40QFN20-D6-ZL-P 40 pad QFN MLF adapter is wired one to one. 40 pad QFN MLF adapter is wired one to one. $320.00
40QFN20-D6-ZL-P 40 pad QFN MLF adapter is wired one to one. 40 pad QFN MLF adapter is wired one to one. $320.00
40SOJ40-D6-ZO 40 Pin adapter for devices in 4O0 mil wide body SOIC packages. Generic one to one wiring. DIP pins are round solder-tail. 40 Pinadapter for devices in 400 mil wide body SOIC packages. Generic one to one wiring.
  • For 40 pin SOIC package
  • 400 mil Component body width
  • Open top ZIF socket
  • Bottom pins are square or round and DIP rows are 800 mils apart
$120.00
40SO50-D6-ZO-P 40 Pin adapter for devices in 440 mil wide body SOIC packages. Generic one to one wiring. DIP pins are square wire wrap. 40 Pin adapter for devices in 440 mil wide body SOIC packages. Generic one to one wiring.
  • For 40 pin SOIC package
  • 11.4mm Chip body width
  • 14.1mm Leads Tip to tip
  • Body length not needed - Open ended socket -
  • 1.27mm (50 mil) pitch
  • Replaceable ZIF socket is OTS-40-1.27-01
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$145.00
40SO50-D6-ZO-S 40 Pin adapter for devices in 440 mil wide body SOIC packages. Generic one to one wiring. DIP pins are round solder-tail. 40 Pin adapter for devices in 440 mil wide body SOIC packages. Generic one to one wiring.
  • For 40 pin SOIC package
  • 11.4mm Chip body width
  • 14.1mm Leads Tip to tip
  • Body length not needed - Open ended socket -
  • 1.27mm (50 mil) pitch
  • Replaceable ZIF socket is OTS-40-1.27-01
  • Bottom pins are round solder-tail and DIP rows are 600 mils apart
$145.00
40TS20-D6-ZL-P 40 Pin adapter for TSOP Type 1 packge. Generic one to one wiring. 40 Pinadapter for TSOP Type 1 packge. Generic one to one wiring.
  • For 40 pin TSOP Type 1 package
  • 0.5mm Pitch
  • 18.0mm Component body length
  • 20.0mmTip-to-tip
  • Closed top Yamaichi IC51-0402-1174 ZIF socket
  • Bottom pins are square 25 mil wire wrap, and DIP rows are 600 mils apart
$80.00
40TS20-D6-ZL-S 40 Pin adapter for TSOP Type 1 packge. Generic one to one wiring. 40 Pinadapter for TSOP Type 1 packge. Generic one to one wiring.
  • For 40 pin TSOP Type 1 package
  • 0.5mm Pitch
  • 18.0mm Component body length
  • 20.0mm Tip-to-tip
  • Closed top Yamaichi IC51-0402-1174 ZIF socket
  • Bottom pins are square 14 mil round solder-tail, and DIP rows are 600 mils apart
$80.00
40TS20-D6-ZO 40 Pin TSOP adapter for 16 bit wide memories in 40 lead 14mm tip to tip TSOP Type 1 package. 40 Pin TSOP adapter for 16 bit wide memories in 40 lead 20mm tip to tip TSOP Type 1 package.
  • For TSOP Type 1
  • 40 pin package
  • 40 pin DIP plug
  • 0.5mm Pitch
  • Package body width 12.0mm
  • 14.0mm Tip to tip
  • Open Top ZIF socket
  • DIP rows are 600 mils apart
$110.00

Part Number   44 Pin    Price Shopping Cart
44PL-D6-ZAL 44 Pin PLCC open top ZIF socket to DIP male pins. This adapter is wired one-to-one. 44 Pin PLCC open top ZIF socket to DIP male pins. This adapter is wired one-to-one.
  • Plastic PLCC Package Type
  • 44 Pins PLCC ZIF open to socket to 44 Pin DIP
  • Pins are wired one-to-one
  • DIP rows are 600 mils apart
$195.00
44PL-D3-ZL-P 44 Pin PLCC closed top clamshell type ZIF socket to 300 mil DIP pins. This adapter is wired one-to-one. 44 Pin PLCC closed top clamshell type ZIF socket to DIP pins on 100 mil centers, 300 mils apart. This adapter is wired one-to-one.
  • Plastic 44 pin PLCC Package
  • Pins are wired one-to-one
  • DIP rows are 300 mils apart
  • 25 mil wire wrap DIP pins
  • Replacement ZIF socket is IC51-0444-400
$300.00
44PL-PL-PG-ZL 44 Pin PLCC closed top clamshell type ZIF socket to PLCC male plug. This adapter is wired one-to-one. 44 Pin PLCC closed top clamshell type ZIF socket to PLCC male plug. This adapter is wired one-to-one.
  • Plastic PLCC Package Type
  • 44 Pin PLCC ZIF socket to 44 Pin PLCC Male Plug
  • Pins are wired one-to-one
$300.00
C44QFN20-D6-ZL-P 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one. $300.00
44QFN20L-D6-ZL-P 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • For 44 pad QFN MLF package
  • 7.0 x 7.0mm (0.276 x 0.276 inch) Component body width
  • 0.50mm Pitch device
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • The QFN top middle pad is connected to pin DIP 1. All other pins are one to one in sequence.
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
$300.00
44QFN20-40D6-ZL-CNPC-P 44 Pad QFN 80C51 microprocessor to 40 pin DIP 44 pad QFN MLF adapter is wired for DIP adapter for QFN package 80C51 microprocessor.
  • For 44 Pad QFN 80C51 microprocessor to 40 pin DIP
  • The center QFN pad on each side is not wired.
  • 7.0 x 7.0mm (0.276 x 0.276 inch) Component body width
  • 0.50mm Pitch device
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • The QFN top middle pad is connected to an adapter test point via
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
$300.00
44QFN20-48D6-ZL-P-AT90SC25672 44 Pad QFN AT90SC25672 microprocessor to 44 pin DIP 44 pad QFN MLF adapter is wired one to one.
  • For 44 Pad QFN AT90SC25672 microprocessor to 48 pin DIP
  • The center QFN pad on each side is not wired.
  • 7.0 x 7.0mm (0.276 x 0.276 inch) Component body width
  • 0.50mm Pitch device
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • The QFN top middle pad is connected to an adapter test point via
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
$300.00
44QFN26L-D6-ZL-P 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • For 44 pad QFN MLF package
  • 8.0mm (0.315 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • All other pins are one to one.
  • Pin connection image.
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$300.00
44QFN26L-D6-ZL-S 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • For 44 pad QFN MLF package
  • 8.0mm (0.315 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • All other pins are one to one.
  • Pin connection image.
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are round 18 mil solder-tail and DIP rows are 600 mils apart.
$300.00
44QFN26R-D6-ZL-P 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • For 44 pad QFN MLF package
  • 8.0mm (0.315 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • QFN 1 to DIP pin 44. All other pins are one to one.
  • Pin connection image.
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart
$300.00
44QFN26R-D6-ZL-R 44 Pin QFN MLF adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • For 44 pad QFN MLF package
  • 8.0mm (0.315 inch) Component body width
  • Pitch 0.65mm (25.6 mil)
  • QFN 1 to DIP pin 44. All other pins are one to one.
  • Pin connection image.
  • Compatible QFN IC Package Drawing
  • Closed top clamshell ZIF socket
  • Bottom pins are round 18 mil solder-tail and DIP rows are 600 mils apart
$300.00
44QFS31-D3-ZO 44 Pin QFN MLF adapter is wired one to one. 44 pin QFP adapter is wired one to one.
  • For 44 pin QFP package
  • 10.0mm Square Package body width
  • 12.0mm Leads Tip to tip
  • 0.8mm Pitch device
  • Open top ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 300 mils apart
$300.00
44QFS31A-D6-ZL-P 44 Pin QFP to DIP adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • QFP Package Type
  • 44 Pin QFP
  • 10.0mm Package Package body width
  • 13.9mm Leads Tip to tip
  • 0.8mm Pitch device
  • Closed top clamshell ZIF socket
  • The QFP socket top middle pad is connected to DIP pin 1. All other pins are one to one in sequence.
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
$300.00
44QFS31A-D9-ZL-P 44 Pin QFP to DIP adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • QFP Package Type
  • 44 Pin QFP
  • 10.0mm Package Package body width
  • 13.9mm Leads Tip to tip
  • 0.8mm Pitch device
  • Closed top clamshell ZIF socket
  • The QFP socket top middle pad is connected to DIP pin 1. All other pins are one to one in sequence.
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 900 mils apart.
$310.00
44QFS31D-D6-ZL-P 44 Pin QFP to DIP adapter is wired one to one. 44 pad QFN MLF adapter is wired one to one.
  • QFP Package Type
  • 44 Pin QFP
  • 10.0mm Package Package body width
  • 12.6mm Leads Tip to tip
  • 0.8mm Pitch device
  • Closed top clamshell ZIF socket
  • The QFP socket top middle pad is connected to DIP pin 1. All other pins are one to one in sequence.
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
$300.00
44SOJ40-D6-ZO-P 44 Pin adapter for devices in 400 mil wide body SOJ packages. Generic one to one. 44 Pin adapter for devices in 400 mil wide body SOJ packages. Generic one to one.
  • For 44 pin SOJ package
  • 400 mil Component body width
  • Open top ZIF socket
  • Replacement socket is Yamaichi no. IC107-4404-106-G
  • Bottom pins are square wire wrap and DIP rows are 600 mils apart
$125.00
44SOJ40-D6-ZO-S 44 Pin adapter for devices in 400 mil wide body SOJ packages. Generic one to one. 44 Pin adapter for devices in 400 mil wide body SOJ packages. Generic one to one.
  • For 44 pin SOJ package
  • 400 mil Component body width
  • Open top ZIF socket
  • Replacement socket is Yamaichi no. IC107-4404-106-G
  • Bottom pins are round solder pin and DIP rows are 600 mils apart
$125.00
44SO52-D6-ZL 44 Pin addapter for devices in 520 mil wide body SOIC packages. Generic one to one wiring. 44 Pin adapter for devices in 520 mil wide body SOIC packages. Generic one to one wiring.
  • For 44 pin SOIC package
  • 520 mil Component body width
  • Closed top clamshell ZIF socket
  • Bottom pins are round and DIP rows are 600 mils apart
$156.00
44SO53-D6-ZL 44 Pin addapter for devices in 530 mil wide body SOIC packages. Generic one to one wiring. 44 Pin adapter for devices in 530 mil wide body SOIC packages. Generic one to one.
  • For 44 pin SOIC package
  • 530 mil Component body width
  • Closed top clamshell ZIF socket
  • Bottom pins are round and DIP rows are 600 mils apart
$156.00
44TST2-30-D3-ZO   44 Pin, 300 mil wide TSOP adapter for 44 lead TSOP Type 2 package.
  • For TSOP Type 2
  • 44 pin package
  • 44 pin DIP plug
  • 0.8mm Pitch
  • Open Top ZIF socket
  • DIP rows are 300 mils apart
  • For 16 bit wide memories
  • Works with EMP10,EMP11,EMP20,EMP30 and similar programmers
$195.00
44TST2-30-D6-ZO   40 Pin, 300 mil wide TSOP adapter for 44 lead TSOP Type 2 package
  • For TSOP Type 2
  • 44 pin package
  • 44 pin DIP plug
  • 0.8mm Pitch
  • Open Top ZIF socket
  • DIP rows are 600 mils apart
  • For 16 bit wide memories
  • Works with EMP10,EMP11,EMP20,EMP30 and similar programmers
$195.00

Part Number   48 Pin    Price Shopping Cart
AD-48TS-48DIP ICE Technology 48 Pin aAdapter for a 48 pin TSOP Type 1 Package. Pins are wired one to one from TSOP to DIP pins. 48 Pin adapter for a 48 pin TSOP Type 1 Package. Pins are wired one to one from TSOP to DIP pins.
  • 48 Pin TSOP Type 1 Package Type
  • TSOP to DIP pins are wired one to one sequentially
  • 20.0mm Leads Tip to tip
  • 18.4mm Package width
  • 0.50mm pitch
  • Open top ZIF socket
  • Bottom pins are square 25 mil wire-wrap.
  • DIP pins are on 100 mil centers. Rows are 600 mils apart
$225.00
48QFN16-D6-ZL-P 48 Pin adapter for 6 x 6mm body, 0.4mm pich packages. Generic one to one. 48 Pin adapter for 6 x 6mm body, 0.4mm pich packages. Generic one to one.
  • For 48 pad QFN MLF package
  • 6 x 6mm Body
  • Pitch 0.4mm
  • Closed top clamshell ZIF socket
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 600 mils apart.
  • DIP pins are on 100 mil centers. Rows are 600 mils apart
$355.00
48QFN16-D6-ZL-S 48 Pin adapter for 6 x 6mm body, 0.4mm pich packages. Generic one to one. 48 Pin adapter for 6 x 6mm body, 0.4mm pich packages. Generic one to one.
  • For 48 pad QFN MLF package
  • 6 x 6mm Body
  • Pitch 0.4mm
  • Closed top clamshell ZIF socket
  • Bottom pins are round solder tail and DIP rows are 600 mils apart.
  • DIP pins are on 100 mil centers. Rows are 600 mils apart
$355.00
48QFN20-D6-ZL-P 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one. 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one.
  • For 48 pad QFN MLF package
  • 7 x 7mm Body
  • Pitch 0.5mm
  • Closed top clamshell ZIF socket
  • Bottom pins are square wire wrap
  • DIP pins are on 100 mil centers. Rows are 600 mils apart
$335.00
48QFN20-D9-ZL-P 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one. 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one.
  • For 48 pad QFN MLF package
  • 7 x 7mm Body
  • Pitch 0.5mm
  • Closed top clamshell ZIF socket
  • Bottom pins are square wire wrap
  • DIP pins are on 100 mil centers. Rows are 900 mils apart
$345.00
48QFN20-D6-ZL-S 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one. 48 Pin adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one.
  • For 48 pad QFN MLF package
  • 7 x 7mm Body
  • Pitch 0.5mm
  • Closed top clamshell ZIF socket
  • Bottom pins are round solder tail
  • DIP pins are on 100 mil centers. Rows are 600 mils apart
$335.00
48QFN20-D6-ZO-P 48 Contact QFN MLF adapter for 48-lead, 0.5mm pitch QFN MLF package adapter. 48 Pin Open top adapter for 7 x 7mm body, 0.5mm pich packages. Generic one to one.
  • QFN MLF 48 pin package
  • Open top socket
  • Pitch 0.5mm
  • 48 DIP wire wrap pins
  • Open Top ZIF socket
  • DIP rows are 600 mils apart
$335.00
48QFS20-D3-ZO-P 48 Contact TQFP QFP socket to DIP pins adapter. 48 Contact SQFP socket to DIP pins adapter.
  • For 48 pin QFP package
  • Pins wired 1 to 1
  • Open Top ZIF socket For
  • 7.0mm Package body width
  • 9.0mm IC Leads Tip to tip
  • 0.5mm Pitch
  • DIP pins are 25 mil square wire wrap on 100 mil centers. Rows are 300 mils apart
$220.00
48QFS20-D6-ZO-P 48 Contact TQFP QFP socket to DIP pins adapter. 48 Contact SQFP socket to DIP pins adapter.
  • For 48 pin QFP package
  • Pins wired 1 to 1
  • Open Top ZIF socket For
  • 7.0mm Package body width
  • 9.0mm IC Leads Tip to tip
  • 0.5mm Pitch
  • DIP pins are 25 mil square wire wrap on 100 mil centers. Rows are 600 mils apart
$220.00
48QFS20-D9-ZO-P 48 Contact TQFP QFP socket to DIP pins adapter. 48 Contact SQFP socket to DIP pins adapter.
  • For 48 pin QFP package
  • Pins wired 1 to 1
  • Open Top ZIF socket For
  • 7.0mm Package body width
  • 9.0mm IC Leads Tip to tip
  • 0.5mm Pitch
  • DIP pins are 25 mil square wire wrap on 100 mil centers. Rows are 900 mils apart
$230.00
48QFS20-D6-ZO-S 48 Contact TQFP QFP socket to DIP pins adapter. 48 Contact TQFP QFP socket to DIP pins adapter.
  • For 48 pin QFP package
  • Pins wired 1 to 1
  • Open Top ZIF socket For
  • 7.0mm Package body width
  • 9.0mm IC Leads Tip to tip
  • 0.5mm Pitch
  • DIP pins are 20 mil round solder-tail on 100 mil centers. Rows are 600 mils apart
$220.00
C48TS20-D6-ZO 48 Pin TSOP adapter for 20mm tip to tip TSOP Type 1 package. 48 Pin TSOP to DIP adapter for 20mm tip to tip TSOP Type 1 package. $150.00
48TS20-D6-ZO-S 48 Pin TSOP adapter for 20mm tip to tip TSOP Type 1 package. 48 Pin TSOP to DIP adapter for 20mm tip to tip TSOP Type 1 package. $150.00
48TS20-D6-ZO 48 Pin TSOP adapter for 20mm tip to tip TSOP Type 1 package. 48 Pin TSOP to DIP adapter for 20mm tip to tip TSOP Type 1 package. $150.00

Part Number   54 Pin    Price Shopping Cart
54SSOS40-D9-SSOS-ZO   54 Pin TSOP type 2 adapter that is wired one-to-one.
  • TSOP Type 2 Package
  • 54 Pins
  • Pitch 0.80mm
  • Body width 10.16mm (0.4 inch)
  • Tip to tip 11.8mm (0.701 inch)
  • Compatible TSOP type 2 Package Drawing
  • Pins are wired one-to-one
  • DIP rows are 900 mils apart
  • DIP pins are 18 mil round solder-tail
$250.00
54TS2-40-D6-ZO 54 Pin TSOP type 2 adapter that is wired one-to-one. 54 Pin TSOP type 2 adapter that is wired one-to-one.
  • TSOP Type 2 Package
  • 54 Pins
  • Pitch 0.80mm
  • Body width 10.16mm (0.4 inch)
  • Tip to tip 11.8mm (0.701 inch)
  • Compatible TSOP type 2 Package Drawing
  • Pins are wired one-to-one
  • DIP rows are 600 mils apart
  • DIP pins are 25 mil square wire-wrap
$250.00

Part Number   56 Pin    Price Shopping Cart
56QFN20-D9-ZL-S-L 56 Pin QFN adapter that is wired one-to-one. 56 Pin QFN adapter that is wired one-to-one.
  • QFN and MLF Package Type
  • Socket is Loranger no. 03734-571-6218A
  • For IC molded body widh 8 x 8mm
  • Pitch 0.50mm
  • 14 contacts on 4 sides, & center pin contact
  • Pins are wired one-to-one
  • DIP Pins are round 18 mil
  • DIP rows are 900 mils apart
$350.00
56QFN20-PG-ZL-S-L 56 Pin QFN adapter that is wired one-to-one. 56 Pin QFN adapter that is wired one-to-one.
  • QFN and MLF Package Type
  • Socket is Loranger no. 03734-571-6218A
  • For IC molded body widh 8x8mm
  • Pitch 0.50mm
  • 14 contacts on 4 sides, & center pin contact
  • Pins are wired one-to-one
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • Breadboard pins are arranged in 11 x 11 matrix on 0.10 inch centers
$350.00
56TS09-D9-ZO-S ZIF Test socket for TSOP type 2 package to DIP breadboard adapter. Converts SMT package with pitch of 5mm to two 900 mil DIP DIP Pin rows. DIP pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14 so that this adapter can be plugged directly into a DIP socket for the same chip in a DIP package. 56 Contact ZIF Test socket for TSOP type 2 package to DIP breadboard adapter. Converts SMT package with pitch of 5mm to two 900 mil DIP DIP Pin rows. DIP pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14 so that this adapter can be plugged directly into a DIP socket for the same chip in a DIP package.
  • TSOP Package Type 1
  • Compatible TSOP Type 2 Package
  • 56 Pins
  • 8.1mm (319 mil) Leads Tip to tip
  • 6.2mm (244 mil) Package body width
  • 14.0mm (551 mil) Package body length
  • 0.50mm (20 mil) pitch
  • Pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14.
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP rows are 900 mills apart
$153.00
56TS20-D9-ZO-S 56 pad ZIF Test socket for TSOP package to DIP breadboard adapter converts SMT package with pitch of 5mm to two 900 mil DIP DIP Pin rows. DIP pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14 so that this adapter can be plugged directly into a DIP socket for the same chip in a DIP package. 56 Contact ZIF Test socket for TSOP package to DIP breadboard adapter converts SMT package with pitch of 5mm to two 900 mil DIP DIP Pin rows. DIP pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14 so that this adapter can be plugged directly into a DIP socket for the same chip in a DIP package.
  • Compatible TSOP Type 1 Package Type
  • TSOP Package Type 1
  • 56 Pins
  • 0.5mm (0.020") Pitch device
  • 20.0mm Leads Tip to tip
  • 14.0mm Package width
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • Pin 1 is connected to TSOP pin 15 and DIP pin 56 is connected to TSOP pin 14.
  • DIP rows are 900 mills apart
$143.00

Part Number   64 Pin    Price Shopping Cart
64QFN20-64D9-ZL-S 64 Pin QFN Closed top adapter that is wired one to one. 64 Pin QFN Closed top adapter that is wired one to one.
  • QFN and MLF Package Type
  • Closed top socket
  • For QFN molded body widh 9x9mm
  • Pitch 0.50mm
  • 16 contacts on 4 sides, & center pin contact
  • Connections
  • Pins are wired one-to-one
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP rows are 900 mils apart
$370.00
64QFN20-64D9-ZL-S-P 64 Pin QFN Closed top adapter that is wired one to one. 64 Pin QFN Closed top adapter that is wired one to one.
  • QFN and MLF Package Type
  • Closed top socket
  • For QFN molded body widh 9x9mm
  • Pitch 0.50mm
  • 16 contacts on 4 sides, & center pin contact
  • Connections
  • Pins are wired one-to-one
  • Bottom pins are square 25 mil wire-wrap and DIP rows are 900 mils apart
$370.00
64QFN20-64D9-ZO-S 64 Pin QFN open top adapter that is wired one to one. 64 Pin QFN open top adapter that is wired one to one.
  • QFN and MLF Package Type
  • Open top socket
  • For IC molded body widh 9x9mm,
  • Pitch 0.50mm
  • 16 contacts on 4 sides, & center pin contact
  • Connections
  • Pins are wired one-to-one
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP rows are 900 mils apart
$370.00
64QFN20-64D9-ZO-S-P 64 Pin QFN open top adapter that is wired one to one. 64 Pin QFN open top adapter that is wired one to one.
  • QFN and MLF Package Type
  • Open top socket
  • For IC molded body widh 9x9mm,
  • Pitch 0.50mm
  • 16 contacts on 4 sides, & center pin contact
  • Connections
  • Pins are wired one-to-one
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP rows are 900 mils apart
$370.00
64QFS20-D4-ZO-S 64 Pin QFN open top adapter that is wired one to one. 64 Pin QFP adapter that is wired one-to-one.
  • For 64 Pin QFP Package
  • 10.0mm Package body width
  • 12.0mm tip to tip
  • 0.5mm Pitch device
  • Open top socket
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP DIP Pin rows are 400 mils apart on 100 mil centers
$370.00
64QN20-D6-ZL-PIC32MX330 64 Pin QFN Closed top adapter for PIC32MX330, PIC32MX350, PIC32MX370, PIC32MX430, PIC32MX450, PIC32MX470. 64 Pin QFN Closed top adapter for PIC32MX330, PIC32MX350, PIC32MX370, PIC32MX430, PIC32MX450, PIC32MX470.
  • QFN and MLF Package Type
  • Closed top socket
  • For PIC32MX330, PIC32MX350, PIC32MX370, PIC32MX430, PIC32MX450, PIC32MX47 components in QFN 9x9mm molded body package.
  • Pitch 0.50mm
  • 16 contacts on 4 sides, & center pin contact
  • Bottom pins are 25 mil wire wrap pins and DIP rows are 600 mils apart
$370.00
C64QFS20-D4-ZO 64 Contact TQFP QFP socket to DIP pins adapter. 64 Contact TQFP QFP socket to DIP pins adapter.
  • For 64 pin QFP package
  • Pins wired 1 to 1
  • Pin Connections
  • 64 Pin Open Top TQFP socket
  • 10.0mm Package Package body width
  • 12.0mm Leads Tip to tip
  • 0.5mm Pitch device
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP pins are on 100 mil centers. DIP rows are 400 mils apart
$220.00
64QFS20-D9-ZL 64 Contact TQFP QFP socket to DIP pins adapter. 64 Contact TQFP QFP socket to DIP pins adapter.
  • For 64 pin QFP package
  • Pins wired 1 to 1
  • Pin Connections
  • 64 Pin Closed top clamshell socket
  • 10.0mm Package Package body width
  • 12.0mm Leads Tip to tip
  • 0.5mm Pitch device
  • Pins are 25 mil square wire-wrap type
  • DIP pins are on 100 mil centers. DIP rows are 900 mils apart
$310.00
64QFS20-D11-ZL 64 Contact TQFP QFP socket to DIP pins adapter. 64 Contact TQFP QFP socket to DIP pins adapter.
  • For 64 pin QFP package
  • Pins wired 1 to 1
  • Pin Connections
  • 64 Pin Closed top clamshell socket
  • 10.0mm Package Package body width
  • 12.0mm Leads Tip to tip
  • 0.5mm Pitch device
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP pins are on 100 mil centers. DIP rows are 1.1 inch apart
$310.00
64TST2-47-ZO-D6 64 Pin TSOP Type 2 adapter that is wired one to one. 64 Pin TSOP Type 2 adapter that is wired one-to-one.
  • For TSOP Package Type 2
  • 0.8mm (0.0315 inch) Pitch device
  • 12.0mm (0.472 inch) Package body width
  • 14.25mm (0.561 inch) Leads tip to tip
  • Open top socket
  • Pins are round solder-tail 0.46mm (18 mil) diameter
  • DIP DIP Pin rows are 600 mils on 100 mil centers
$370.00

Part Number   66 Pin    Price Shopping Cart
66SSOS40-D9-ZO-S 66 Open top to DIP SSOP adapter that is wired one to one. 66 Pin Open top SSOP adapter that is wired one to one.
  • SSOP Package Type
  • 66 Pin open top socket
  • 10.20mm (402 mil) Package body width
  • 11.80mm (465 mil) Leads Tip to tip
  • 0.65mm (25.6 mil) Pitch device
  • Pins are wired one-to-one
  • Bottom pins are round solder tail pins and DIP rows are 900 mils apart
$125.00

Part Number   68 Pin    Price Shopping Cart
68-PLCC-DIP12 68 Pin PLCC socket on a 0.1 inch hole pattern male pin breadboard pattern. DIP rows pins are 1.2 inches apart. 68 Pin PLCCsocket on a 0.1 inch hole pattern male pin breadboard pattern. DIP rows pins are 1.2 inches apart.
  • 68 pin PLCC socket
  • Pins are wired one-to-one
  • 24.23mm x 24.23mm
  • 1.27mm Pitch device
  • DIP rows are 25 mil square pins 1.2 inches apart
$125.00

Part Number   80 Pin    Price Shopping Cart
80QFR31-PG-ZL-P 0.8mm Pitch, 8O Pin TQFP socket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern. 0.8mm Pitch, 8O Pin TQFPsocket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern.
  • Hinge lid clamshell socket
  • 80 Pins
  • 0.8mm (32 mil) Pitch device
  • 17.2 x 23.2mm (677 x 913 mils) Leads Tip to tip
  • 14 x 20mm (551 x 787 mils) body
  • Replacement ZIF socket is FPQ-80-0.08-12
  • Square wire wrap pins are on 100 mil centers
$275.00
80QFR31C-PG-ZL 0.8mm Pitch, 8O Pin TQFP socket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern 0.8mm Pitch, 8O Pin TQFPsocket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern.
  • Hinge lid clamshell socket
  • 80 Pins
  • 0.8mm (32 mil) Pitch device
  • 17.9 x 23.9mm (705 x 941 mils) Leads Tip to tip
  • 14 x 20mm (551 x 787 mils) body
  • Replacement ZIF socket is IC51-0804-819-1
  • Has square wire wrap pins that are on 100 mil centers
$275.00
80QFR31C-PG-ZL-S 0.8mm Pitch, 8O Pin TQFPsocket to wire-wrap 25 mil square pins for a 0.1 inch breadboard hole pattern.
  • Hinge lid clamshell socket
  • 80 Pins
  • 0.8mm (32 mil) Pitch device
  • 17.9 x 23.9mm (705 x 941 mils) Leads Tip to tip
  • 14 x 20mm (551 x 787 mils) body
  • Replacement ZIF socket is IC51-0804-819-1
  • Has round solder tail pins that are on 100 mil centers
$275.00
80QFS20-PG-ZL 0.5mm Pitch, 8O Pin TQFP socket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern. 0.5mm Pitch, 8O Pin TQFPsocket to 25 mil wire-wrap square pins for a 0.1 inch breadboard hole pattern.
  • Yamaichi IC51-0804-808 clamshell socket
  • Hinge lid clamshell socket
  • QFP Package Type
  • 80 Pins
  • 12x12mm Body size
  • 14.0mm Leads tip to tip
  • 0.5mm Pitch device
  • Wire wrap pins are on 100 mil centers
$275.00
80QFS26D-PG-ZO-S 0.65mm Pitch, 8O Pin TQFP socket to solder-tail pins for a 0.1 inch breadboard hole pattern. 0.65mm Pitch, 8O Pin TQFPsocket to solder-tail pins for a 0.1 inch breadboard hole pattern.
  • Replacement ZIF socket is 3014-080-6-08
  • Compatible QFP Package Drawing
  • QFP Package Type
  • 80 Pins
  • 14x14mm Body size
  • 16.0mm Leads tip to tip
  • 0.65mm (25.6 mil) Pitch device
  • Solder-tail round pins are on 100 mil centers
$275.00

Part Number   100 Pin    Price Shopping Cart
100QFR26C-PG-ZL-S 100QFP Adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern. 100QFP Adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern.
  • Yamaichi IC51-1004-814 QFP TQFP 100 pin socket
  • 14.0 x 16.0mm (551 x 630 mil) Chip body width
  • 23.2 x 17.2mm (678 x 913 mil) Leads Tip to tip
  • 0.65mm (25.6 mil) Pitch device
  • 100 pins to 13 x 13 PGA 0.10 inch standard breadboard matrix
$235.00
100QFS16-PG15X2-XL-S-Y 100QFP Adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern. 100QFP Adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern.
  • Yamaichi IC51-1004-1919 QFP TQFP 100 pin socket
  • 12.0 x 12.0mm (472 mil) Chip body width
  • 14.0 x 14.0mm (551 mil) Leads Tip to tip
  • 0.4mm (16 mil) Pitch device
  • 100 pins to 0.10 inch standard breadboard matrix
$245.00
100QFS20-PG-ZL-P 100QFP adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male 25 mil square pin breadboard pattern. 100QFP adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male solder-tail pin breadboard pattern.
  • Hinge lid clamshell socket
  • QFP Square Package Type
  • 100 Pins
  • 14.0mm (551 mil) Chip body width
  • 16.0mm (630 mil) Leads Tip to tip
  • 0.5mm (20 mil) Pitch device
  • 25 mil square pins
  • Common Applications - Microchip microcontrollers PIC18C958, PIC18F96J60, PIC18F96J65, PIC18F97J60, PIC24FJ64GA010, PIC24FJ96GA010, PIC24FJ128GA010, PIC24FJ64GB110, PIC24FJ128GB110, PIC24FJ192GB110, PIC24FJ256GB110, PIC24FJ118GA110, PIC24FJ192GA110, PIC24FJ256GA110, PIC24HJ64GP210, PIC24HJ64GP510, PIC24HJ128GP210, PIC24HJ128GP510, PIC24HJ128GP310, PIC24HJ256GP210, PIC24HJ256GP610, PIC32MX320F128L, PIC32MX340F128L, PIC32MX360F256L, PIC32MX360F512L, PIC32MX440F128L, PIC32MX460F256L, PIC32MX460F512L, dsPIC33FJ64GP310, dsPIC33FJ64GP710, dsPIC33FJ128GP310, dsPIC33FJ128GP710, dsPIC33FJ256GP510, dsPIC33FJ256GP710, dsPIC33FJ64MC510, dsPIC33FJ64MC710, dsPIC33FJ128MC510, dsPIC33FJ128MC710
$235.00
100QFS20-PG-ZL-S 100QFP adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male solder-tail pin breadboard pattern. 100QFP adapter with hinge lid test ZIF QFP socket on a 0.1 inch hole pattern male solder-tail pin breadboard pattern.
  • Hinge lid clamshell socket
  • QFP Square Package Type
  • 100 Pins
  • 14.0mm (551 mil) Chip body width
  • 16.0mm (630 mil) Leads Tip to tip
  • 0.5mm (20 mil) Pitch device
  • 25 mil round solder-tail pins
  • Common Applications - Microchip microcontrollers PIC18C958, PIC18F96J60, PIC18F96J65, PIC18F97J60, PIC24FJ64GA010, PIC24FJ96GA010, PIC24FJ128GA010, PIC24FJ64GB110, PIC24FJ128GB110, PIC24FJ192GB110, PIC24FJ256GB110, PIC24FJ118GA110, PIC24FJ192GA110, PIC24FJ256GA110, PIC24HJ64GP210, PIC24HJ64GP510, PIC24HJ128GP210, PIC24HJ128GP510, PIC24HJ128GP310, PIC24HJ256GP210, PIC24HJ256GP610, PIC32MX320F128L, PIC32MX340F128L, PIC32MX360F256L, PIC32MX360F512L, PIC32MX440F128L, PIC32MX460F256L, PIC32MX460F512L, dsPIC33FJ64GP310, dsPIC33FJ64GP710, dsPIC33FJ128GP310, dsPIC33FJ128GP710, dsPIC33FJ256GP510, dsPIC33FJ256GP710, dsPIC33FJ64MC510, dsPIC33FJ64MC710, dsPIC33FJ128MC510, dsPIC33FJ128MC710
$235.00

Part Number   128 Pin    Price Shopping Cart
128QFR20-PG-ZL-S 128 Pin rectangular QFP socket on a 0.1 inch hole pattern male pin breadboard pattern. 128 pin QFP Adapter with open top test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern.
  • 128 pins to 14 x 3 PGA 0.10 inch standard breadboard matrix
  • Pin numbering pdf
  • QFP Package Type
  • 128 Pins
  • 14.0mm X 20.0mm rectanglar components
  • 17.2mm x 23.2mm tip to tip
  • 0.5mm Pitch device
  • Replacement ZIF socket is IC51-1284-1433-10
$425.00

Part Number   144 Pin    Price Shopping Cart
144QFS20-PG-ZO-S 144 pin QFP Adapter with open top ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern. 144 QFP Adapter with open top test ZIF QFP socket on a 0.1 inch hole pattern male pin breadboard pattern.
  • 144 pins to 15 x 15 PGA 0.10 inch standard breadboard matrix
  • Pin numbering pdf
  • 20.0mm Package Chip body width
  • 22.0mm Leads Tip to tip
  • 0.50mm Pitch device
  • Replacement ZIF socket is 3020-144-6-08
$435.00

Part Number   160 Pin    Price Shopping Cart
M160-QFS26A-PG-ZL-S 160 Pin QFP Adapter with closed top clamshell ZIF socket to 0.1 inch breadboard pins. 160 Pin QFP Adapter with closed top clamshell ZIF socket to 0.1 inch breadboard pins.
  • For 160 pin QFP package
  • Closed top test socket
  • Top has 25 mil square test connection pins
  • Square pins are on 100 mil centers. Inside rows are 1.3 inches from the adapter center. Out side rows are 1.4 inches from center
  • 0.65mm (25.6 mil) Pitch device
  • 28.0mm (1.1")Square package body width
  • 31.2 x 31.2mm (1.23") Leads tip to tip
  • Removable test socket mounting
  • Replacement ZIF socket is IC51-1604-845-4
$475.00

Part Number   208 Pin    Price Shopping Cart
208QFS20-PG-ZO-S 208 Pin QFP adapter with open top ZIF socket to 0.1 inch breadboard pins. 208 Pin QFP adapter with open top ZIF socket to 0.1 inch breadboard pins.
  • For 208 pin QFP package
  • .50mm (20 mil)Pitch device
  • 28.0mm (1.10")Square component body
  • 30.0mm (1.18) Leads tip to tip
  • Removable test socket mounting
  • Replacement ZIF socket is 3028-208-6-08
$850.00

Part Number   256 Pin    Price Shopping Cart
256QFS16-PG-ZL-S 256 Pin QFP adapter with closed top clamshell ZIF socket to 0.1 inch breadboard pins. 256 Pin QFP adapter with closed top clamshell ZIF socket to 0.1 inch breadboard pins.
  • For 256 pin QFP package
  • Pitch 0.4mm (15.7 mil)
  • 28mm (1.1") Wide square component body
  • 30.6mm (1.20")Leads tip to tip
  • Removable test socket mounting
  • Replacement ZIF socket is FPQ-256-0.4-02
$990.00


Aprilog address

Previous page     Home page     Email us.

Accepted payment from
Google
Aprilog is a Division of Enable Engineering Co., Inc.
